Device Type: 1×32 PLC (Planar Lightwave Circuit) Fiber Optic Splitter Module
Brand/Model: Optace – 1:32, SC/UPC, ABS Box
Video Output: N/A (Passive optical component; no video interface)
Data Ports: 1× Input Port, 32× Output Ports; SC/UPC Connectors
Optical & Fiber Specifications:- Fiber Type: Single-mode G.657A1 or G.652D
- Operating Wavelength: 1260 – 1650 nm
- Insertion Loss: Typical ≤ 17.2 dB (Standard grade); some Optace/industry listings cite ≤ 16.5 dB (Premium/P-grade)
- Return Loss: ≥ 50 dB (SC/UPC)
- Uniformity: ≤ 1.5 – 2.0 dB (typical for 1×32 class)
- Polarization Dependent Loss (PDL): ≤ 0.3 dB
- Directivity: ≥ 55 dB
- Fiber Length: Typically 1 m or 1.5 m (varies by supplier)
Physical & Environmental:- Package Style: ABS Plastic Box (Module)
- Dimensions (L × W × H): Approx. 120 × 80 × 18 mm (varies slightly by manufacturer; some list 100×80×10 mm for lower counts)
- Operating Temperature: −40°C to +85°C
- Storage Temperature: −40°C to +85°C
Key Specs: Optace 1×32 PLC Fiber Splitter, SC/UPC Connectors, ABS Box Module, 1260–1650 nm, Insertion Loss ≤17.2 dB (Typical), Return Loss ≥50 dB, Uniformity ≤1.5 dB, PDL ≤0.3 dB, Directivity ≥55 dB, 120×80×18 mm, −40 to +85°C
Usage: FTTx / FTTH Deployments (GPON/EPON/BPON), Passive Optical Networks (PON), CATV Systems, LAN/WAN & Metro Networks, Fiber Optic Test Equipment, Signal Distribution in Centralized or Distributed Splitting Architectures
