Epson LQ-2190 Dot Matrix Printer

Product Overview

The 24 pin wide carriage dot matrix printer supports print speeds of 576 cps at 12 cpi, making the device perfect for large volume tasks. Printed images have a resolution of 360 x 180 dpi. You can print sheet paper, continuous paper both single and multi-layer, labels, roll paper, cardboard, and envelopes with this device. Bidirectional parallel, USB 2.0 Type B interface lets you print directly from your portable drives. A ribbon life of about 15 million characters ensures delayed ribbon replacement cycles, thereby bringing down the maintenance and running costs. Choice of top, bottom, front, and rear paper paths gives you complete control over desk space management. A user-friendly, space-saving design and quiet operations enable the device to fit conveniently into your offices with utmost ease.

Convenient Connectivity

The USB interface is added in addition to the conventional bi-directional parallel interface. Wired/wireless network interfaces and the serial interface can be added as an option according to your system environment. Flexible paper management allows insertion at the front, rear and bottom and dual tractor units allow you to load two sizes of paper at the same time ready for use. The ability to print on 6-part stationery is useful for multipart forms. The Epson LQ-2190 is a 24-pin wide-format printer and like its predecessor – the LQ-2180 – it is a fast, flexible, cost-effective and highly reliable printing solution that combines large print volumes with high letter quality – ideal for applications such as invoices, delivery notes, inventory listings or even labels.

Advanced Onboard Features

The Epson LQ 2190 Dot Matrix Printer’s advanced onboard features make it perfect for large volume tasks in your businesses. This 24 pin wide carriage dot matrix printer prints on a wide range of papers at an impressive 576 cps at 12 cpi. Printed documents have a resolution of up to 360 x 180 dpi. The device can sheet paper, continuous paper both single and multi-layer, labels, roll paper, cardboard, and envelopes at such high speeds.

Built for Performance

The Epson LQ 2190 Dot Matrix Printer has a print head life of 400 million strokes per wire. Its mean time between failure is pegged at 20,000 power-on hours, robust, ergonomic design ensures all your work is completed in a matter of time. A ribbon life of about 15 million characters ensures delayed ribbon replacement cycles. This brings down the maintenance and running costs.

Technical Specifications

• Printing Method- Impact dot matrix
• Number of Pins- 24 pins
• Number of columns- 136 columns
• Pins- 24 Needle
• Printing Speed- LQ: 10 cpi: 120 chars/s, 12 cpi: 144 chars/s, HighSpeed-Draft: 10 cpi: 480 chars/s, 12 cpi: 576 chars/s, Draft: 10 cpi: 360 chars/s, 12 cpi: 432 chars/s
• Carbon Copies- 5 plus one original
• Printing Resolution- 360 x 180 DPI
• Connectivity- USB 2.0 Type B, Wired Network (optional), Type B interface, Bidirectional parallel, RS-232 (optional)
• Document Feed- Single sheet front and rear, Continuous media front and rear, Paper output rear

  Paper Formats- Sheet Paper (single- and multi-layer), Continuous Paper (single- and multi-layer), Labels (single- and multi-layer), Roll Paper, Envelopes, Cardboard

• Power consumption- 46 Watt, 3 Watt (economy)
• Product dimensions- 693‎ x 405 x 268 mm (Width x Depth x Height)
• Product weight- 13 kg
• Compatible Operating Systems- Windows 2000, Windows 7, Windows 8, Windows 98, Windows Vista, Windows XP, Windows XP x64
• Included Software- Epson Status Monitor
• Mean Time Between Failures- 20,000 hours
• Print Head Life- 400 Million Strokes/Wire
• Memory- 128 kB Included
• Ribbon Yield- 15000000 characters Black Draft
• What’s in the box- Driver and utilities (CD), Main unit, Power cable, Ribbon, Setup guide, Software (CD), User manual (CD), Warranty document
