KSh 52(KSh 60 Incl VAT)
Device Type: Aerial Drop Cable Clamp (Dead-End / Tension / Wedge Clamp)
Brand/Model: Generic — specifications vary by model and cable type (common references: ADC-CLAMP-5/35, HYPOCUT 92460, ODWAC US, S-Hook Nylon Clamp). Verify the exact code on the physical unit.
Video Output: N/A
Data Ports: N/A (passive mechanical hardware; no electrical or data interfaces)
Cable Compatibility:
Cable Types: Flat drop cable, round drop cable, Figure-8 cable, ADSS flat cable
Cable Diameter Ranges: 2.5–5 mm (round FTTH), 3×6 mm (flat ROC/EZ AXS), 6–9 mm (Figure-8), 9×4 mm (flat ADSS), 2×4 mm max (nylon S-hook style)
Core Capacity: Typically 1–2 core drop cable
Mechanical & Performance:
Hardware Type: Dead-end clamp / Wedge clamp / Tension clamp
Material (Body): Galvanized steel, stainless steel, or UV-resistant thermoplastic (Nylon PA66)
Material (Wedge/Jaw): Galvanized steel, plastic wedges, or thermoplastic
Bail Material: Stainless steel (fixed or flexible)
Max Span Length: 50 m (standard flat ADSS) to 70 m (FTTH round/flat) to 90 m (Figure-8)
Max Tension Load: 1,000 N (100 kg) for flat ADSS; 1,200–1,800 N cutting load for HYPOCUT flat drop; 0.7 kN (min) for nylon S-hook
Weight: 35 g (nylon) to 46 g (steel body) — varies by model
Insertion Loss Impact: <0.1 dB (negligible optical impact)
Installation & Environment:
Mounting: Directly on pole fittings (open/closed eye) or pole hardware with minimum ⌀10–15 mm
Installation Method: Tool-less / quick installation (wedge slides to grip cable); some models support installation with hot stick from ground
Operating Temperature: −10°C to +60°C (standard); some rated down to −60°C
UV Resistance: Yes (UV-rated thermoplastic or galvanized steel)
Compliance: PIA compliant (some models), RoHS compliant
