Device Type: Wireless Screen Sharing Dongle / Transmitter (for Interactive Whiteboards & Displays)
Model / SKU: DHI-PKP-WP0B (official base model: PKP-WP0B)
Brand: Dahua
Hardware:- Input Resolution: 1920 × 1200
- Output Resolution: 1920 × 1080
- Port: 1 × USB 2.0
- Input Voltage: 5 VDC
- Power Consumption: 2.5 W
System Parameters:- Transmission Delay: < 120 ms
- Encryption: CCMP
- Authentication Protocol: WPA2-PSK
- Wireless Transmission Protocol: IEEE 802.11 a/g/n
- Wireless Data Rate: 54 Mbps
- Frame Rate: Windows: 1920 × 1080 @ 25 fps / 1366 × 768 @ 25 fps; iOS: 1920 × 1080 @ 30 fps / 1366 × 768 @ 30 fps
Compatible Operating Systems:- Windows 7, Windows 8, Windows 10
- Mac OS X 10.6, Mac OS X 10.7 and later
Physical:- Net Weight: 63.3 g (0.14 lb)
- Dimensions: 61 mm × 156 mm × 17 mm (2.40" × 6.14" × 0.67")
Environmental:- Operating Temperature: 5°C to 40°C (41°F to 104°F)
- Operating Humidity: 0%–80% (Non-Condensing)
- Transmission Distance: Up to 15 m (Between Wireless Projector and Host)
- Frequency Band: 2.4 GHz and 5 GHz (Recommended)
Key Features:- 1080P Output, Delivering a Crisp Image
- Plug and Play — No Need to Install Software or Drivers
- Hassle-Free, No Need for Cables
- Screen Projection with Just the Press of a Button
- Compatibility with Mainstream Operating Systems
Key Specs: Dahua DHI-PKP-WP0B Wireless Screen Sharing Cable, 1920×1200 Input / 1920×1080 Output, 1× USB 2.0, 5 VDC (2.5W), <120ms Transmission Delay, IEEE 802.11 a/g/n, 54 Mbps Wireless Data Rate, WPA2-PSK / CCMP Encryption, Windows 7/8/10 & Mac OS X 10.6+ Compatible, Up to 15m Transmission Distance, 2.4/5 GHz Dual-Band, 61×156×17mm, 63.3g, 5°C–40°C Operating Temperature, One-Button Projection, Plug & Play
Usage: Wireless Screen Sharing for Interactive Whiteboards & Displays, Corporate Meeting Rooms, Smart Classrooms, Conference & Presentation Environments, Collaborative Workspaces, and Any Installation Requiring Cable-Free, One-Button Content Sharing from Windows or Mac Devices
