Device Type: 32-Channel 1U 16PoE 4K Network Video Recorder (NVR)
Model / SKU: Dahua DHI-NVR5232-16P-4KS2/L (Pro Series)
IP Camera Input: 32 Channels
Max Incoming Bandwidth: 320 Mbps
Max Recording/Playback Resolution: Up to 12MP
Video Output: 1x HDMI (up to 3840×2160 / 4K), 1x VGA
PoE Ports: 16 ports (IEEE 802.3af/at), max 25.5W per port, 130W total budget
Storage: 2x SATA III ports, up to 8TB per HDD (official Eurasia datasheet) (Note: some sources cite 6TB or 12TB—see note below)
Compression: H.265+ / H.265 / H.264+ / H.264 / MJPEG
Network Interface: 1x RJ-45 Gigabit Ethernet (10/100/1000Mbps)
USB Ports: 1x USB 3.0 (rear), 1x USB 2.0 (front)
Alarm I/O: 4-channel Alarm Input, 2-channel Relay Output
Power Supply: Single AC 100–240V (Eurasia datasheet lists AC 220–240V)
Operating Temp: -10°C to +55°C
Form Factor: 1U Rackmount, approx. 375 × 327 × 53 mm, 2.7kg (without HDD)
Key Specs: Dahua DHI-NVR5232-16P-4KS2/L, 32-Ch IP NVR, 320Mbps Bandwidth, 16x PoE Ports (130W), Up to 12MP Resolution, 4K HDMI Output, H.265+/H.265, 2x SATA Bays (up to 8TB each), 4 Alarm In / 2 Alarm Out, Gigabit LAN, 1U Rackmount
Usage: Medium-to-large IP surveillance systems for retail stores, offices, schools, and commercial buildings requiring up to 32 cameras with direct PoE power and 4K recording capability. The 16 built-in PoE ports simplify installation by delivering both power and data to cameras over a single cable.
