Device Type: Standalone Face Recognition Access Controller & Time Attendance Terminal (Indoor)
Model / SKU: DHI-ASI3223GL (official model: ASI3223GL)
Brand: Dahua
Series: ASI3 Series
Display: 4.3-inch LCD Capacitive Touchscreen; Resolution 480 (H) × 272 (V)
Camera: 2-MP CMOS Wide-Angle Dual-Lens HD Camera with Auto IR Illumination, White Light Fill Light, and DWDR (Digital Wide Dynamic Range)
Verification Methods: Face, Password, Remote Unlock, and Combination Unlock; Unlock by Period Supported; Liveness Detection (Anti-Spoofing) Supported
Face Recognition Performance:- Distance: 0.3 m – 1.5 m (0.98 ft – 4.92 ft)
- Height Range: 1.1 m – 2.0 m (3.61 ft – 6.56 ft)
- Accuracy: 99.9% (with Liveness Detection)
- Comparison Speed: 0.2 s per person (1:N)
Capacity:- Users: 1,000
- Faces: 1,000
- Passwords: 1,000
- Records: 150,000 (per distributor listings) / 300,000 (per Pana Compu listing)
Period / Schedule: 128 Period Lists; 128 Holiday Periods
Data Ports & Communication:- Network: 1 × RJ-45 (10/100 Mbps Self-Adaptive Ethernet)
- RS-485: 1 Port
- Wiegand: 1 Port
- USB: 1 × USB 2.0 Port
- Network Protocol: IPv4, RTSP, RTP, TCP, UDP, SIP, P2P; OSDP Protocol Supported
Access Control I/O:- Exit Button: 1
- Lock Control: 1
- Door Status Detection: 1
- Alarm Input: 1
- Alarm Output: 1
Access Control Functions: Anti-passback, Tamper Alarm, Duress Alarm, Door Sensor Timeout, Intrusion Detection
Interoperability: ONVIF; CGI; SDK & API Supported
Power Supply: DC 12V, 1.5A; Power Consumption ≤18W
Casing Material: PC + ABS
Physical:- Dimensions (W×H×D): 116 mm × 107 mm × 22 mm
- Weight: 0.596 kg
- Installation: Surface Mount (Wall Mount Bracket Included)
Environmental: Operating Environment: Indoor Use Only
Key Specs: Dahua DHI-ASI3223GL Standalone Face Recognition Access Controller, 4.3" Touchscreen (480×272), 2MP Dual-Lens Camera with IR & White Light Fill Light & DWDR, Face/Password/Remote/Combination Unlock, Liveness Detection (99.9% Accuracy, 0.2s), 1,000 Users / 1,000 Faces / 1,000 Passwords / 150,000–300,000 Records, 128 Period Lists & Holidays, Anti-passback, Tamper & Duress Alarms, RS-485 / Wiegand / USB 2.0, 10/100M Ethernet, ONVIF/CGI/SDK/API, DC 12V 1.5A (≤18W), PC+ABS Housing, 116×107×22mm, 0.596kg, Surface Mount, Indoor Use
Usage: Single Door Access Control Systems, Office & Commercial Building Entrances, Server Rooms, Data Centers, Retail Stores, Employee Time & Attendance Tracking, and Any Indoor Installation Requiring Reliable Standalone Face Recognition Access Control with Password Verification
