Device Type: Single-Lane Swing Barrier Turnstile (Left Post) for Access Control
Model / SKU: DHI-ASGB110K-L (ASGB110K Series)
Brand: Dahua
Configuration: Left-hand post (no cutout for ASI face recognition terminal). A matching right-hand post (DHI-ASGB110K-R) and center post (DHI-ASGB120K-D) are available for multi-lane setups.
Barrier Arm: Acrylic Arm, 600 mm (23.62") Length; 8.0 mm Thickness
Passage Width: Standard 600 mm; Customizable up to 900 mm
Cabinet Material: SUS 304 Stainless Steel; Body Thickness: 1.0 mm; Top Cover Thickness: 1.2 mm
Motor: Brushless DC Servomotor (Silent Operation)
MCBF: >3,000,000 Cycles
Access Control & Communication:- Authentication Methods: Supports combining card reader, face recognition, fingerprint, QR code, and CPU card readers
- Data Ports: 1 × Wiegand Input Port, 1 × RS-485 Input Port
- Security Modes: 3 Adjustable Security Levels; 9 Passage Mode Combinations
- Functions: Second Authentication, Memorizing Entry/Exit Data, People Counting
- Indicators: Audible and Visual Alarm (Adjustable Volume); Status Light Indicator; Voice Prompt
Protection & Safety:- Anti-Squeeze: Mechanical and IR-Based Anti-Squeeze Protection
- Anti-Collision: Supported
- Fail-Safe: Arm can be manually pushed open during a power failure (no energy storage capacitor)
- Fire Alarm Linkage: Supports normally opening the fire passage and outputting alarm signals
- Ingress Protection: IPX4 (Water Splash Resistance)
- Vandal Resistance: IK04 (Glass Plate); IK07 (Stainless Steel Cabinet)
Performance:- Throughput: 20–70 Persons per Minute
- Unlock/Lock Speed: 0.8 Seconds
Power:- Power Supply: 100–240 VAC, 3 A, 50/60 Hz
- Power Consumption: ≤15 W (Standby); ≤80 W (Working)
Physical:- Dimensions (W×D×H): 1200 × 140 × 980 mm (47.24" × 5.51" × 38.58")
- Net Weight: Approx. 24 kg
Environmental:- Operating Temperature: –25°C to +70°C
- Operating Humidity: 5%–90% (Non-Condensing)
Smart Detection: 4 Pairs of Built-In IR Detectors for Precise Body Height Detection and Passage Width Adjustment
Key Specs: Dahua DHI-ASGB110K-L Swing Barrier Turnstile, Left Post, SUS 304 Stainless Steel (1.0 mm), Acrylic Arm 600mm, Brushless DC Servomotor, MCBF >3 Million Cycles, 20-70 Persons/Min, 0.8s Unlock Speed, 4 Pairs IR Detectors, IPX4, IK04/IK07, 3 Security Modes, 9 Passage Modes, Supports Card/Face/Fingerprint/QR/CPU Card, Wiegand + RS-485, 100-240VAC, 1200×140×980mm, 24kg, -25°C to +70°C
Usage: Office Buildings, Residential Communities, Schools, Factories, Event Venues, and Any Location Requiring Reliable, High-Throughput Pedestrian Access Control with Multiple Authentication Options
