DH-XVR1B08H-1/T

Video & Compatibility

• Penta-brid Input: Supports HDCVI, AHD, TVI, CVBS, and IP cameras with auto-detect on 8 BNC ports .
• 5MP Recording: Records analog cameras up to 5MP@25fps (or 5M-N depending on mode) .
• IP Expansion: Offers 4 native IP channels, expandable to 12 IP channels by converting analog ones. Each IP channel supports up to 6MP .

AI & Smart Features

• SMD Plus (8 Channels): Smart Motion Detection filters alarms to distinguish between humans and vehicles, reducing false alerts from rain or leaves .
• AI Coding: Optimizes the video stream to save storage and bandwidth while preserving details of targets .
• AI Search: Allows quick retrieval of footage based on target classification (Human or Vehicle) .

Storage & Hardware

• Single HDD Bay: Features 1 SATA port supporting a hard drive up to 16TB (specs vary; some sources list 6TB) .
• Compact Chassis: A 1U Cooper form factor with dimensions of 198.3 mm × 203.4 mm × 41.5 mm .
• Video Outputs: Includes 1 HDMI and 1 VGA port, both supporting up to 1080p resolution .

Audio & Connectivity

• Audio over Coaxial: Supports transmitting audio from the camera over the same coaxial cable as video .
• Two-Way Talk: Includes 1 RCA audio input and 1 RCA output for two-way communication .
• Network: Features a 10/100 Mbps RJ-45 Ethernet port for remote access via DMSS or Smart PSS .
