Device Type: 8-Channel Penta-brid WizSense Digital Video Recorder (XVR)
Brand/Model: Dahua DH-XVR1B08-I/T
Video Output: 1x HDMI (up to 1920×1080), 1x VGA (up to 1920×1080)
Data Ports: 8x BNC (HDCVI/AHD/TVI/CVBS auto-detect); 1x RJ-45 10/100 Mbps Ethernet; 2x USB 2.0; 1x SATA (HDD up to 6TB); 1x RCA Audio In; 1x RCA Audio Out; 8x BNC Coaxial Audio
IP Camera Support: Up to 10 channels (2 default + 8 analog convertible); up to 6MP per channel; 40 Mbps incoming bandwidth
Two-Way Talk: 8-channel two-way talk over coaxial cable (the "/T" model feature)
AI Features: 8-channel SMD Plus (human/vehicle filtering); AI Coding; WizSense
Compression: Smart H.265+, H.265, Smart H.264+, H.264
Recording Resolution: 1080N/720P (Main stream: 1st channel up to 25/30fps; others up to 15fps)
HDD Support: 1x SATA port, up to 6TB
Key Specs: Dahua XVR1B08-I/T, 8CH Penta-brid XVR, 1080N/720P, WizSense, 8-Ch Coaxial Two-Way Talk, SMD Plus, AI Coding, Smart H.265+, Up to 10 IP Channels (6MP), 1x HDD up to 6TB, HDMI/VGA
Usage: Small to Medium CCTV Systems, Hybrid Analog/IP Upgrades, Retail/Office/Home Surveillance, Two-Way Audio Communication
