DH-PFA121 Water-proof Junction Box

Datasheet
Physical Specifications

• Material: Aluminum alloy construction for durability .
• Dimensions: 134.0 mm × 133.9 mm × 56.0 mm (L × W × H) .
• Weight: 0.52 kg (net) .
• Color: White .

Protection & Environment

• Ingress Protection: IP66 rated, ensuring protection against dust and powerful water jets .
• Operating Temperature: -40°C to +60°C (-40°F to +140°F) .
• Humidity: <90% (RH) .

Design & Installation

• Cable Management: Contains cable outlets on its bottom and sides to make wiring more convenient .
• Thread Type: G3/4" screw thread .
• Load Bearing: Supports a maximum weight of 3.0 kg .
• Mounting: Designed for junction mount installation .
