KSh 10,630(KSh 12,331 Incl VAT)
Device Type: 6MP WDR IR Vandal-Proof Mini Dome Network Camera (Eco-savvy 3.0 Series)
Model / SKU: DH-IPC-HDBW4631EP-ASE (also listed as IPC-HDBW4631EP-ASE; variants: -0280B for 2.8mm, -0360B for 3.6mm)
Brand: Dahua
Series: Eco-savvy 3.0
Image Sensor: 1/2.9" 6-Megapixel Progressive Scan STARVIS™ CMOS
Max. Resolution: 3072 × 2048 (6MP) @ 20 fps; 2688 × 1520 (4MP) @ 25/30 fps
Min. Illumination: 0.04 Lux @ F1.6 (Color, 1/3s); 0.4 Lux @ F1.6 (Color, 1/30s); 0 Lux with IR On
Lens: Fixed-Focal, 2.8 mm (Standard) / 3.6 mm (Optional / -0360B Variant); Max. Aperture F1.6
Field of View (2.8 mm): Horizontal 98° / Vertical 67°
Field of View (3.6 mm): Horizontal 69° / Vertical 48°
DORI Distance (3.6 mm): Detect 89 m / Observe 36 m
Illumination: Built-in IR LED; Max. IR Distance up to 30 m; Auto/Manual Control
Pan/Tilt/Rotation: Pan 0°–355° / Tilt 0°–65° / Rotation 0°–355°
Video Output: Network Streaming Only (No Analog Video Output)
Video Compression: H.265+ / H.265 / H.264+ / H.264; Triple-Stream Encoding
Frame Rate: Main Stream: 3072 × 2048 @ 1–20 fps; 2688 × 1520 @ 1–25/30 fps
WDR: 120 dB True WDR
Noise Reduction: 3D DNR
Image Enhancements: Day/Night (ICR), AWB, AGC, BLC, HLC, ROI
Data Ports: 1 × RJ-45 (10/100 Base-T Ethernet)
Network Monitoring: Web Viewer, CMS (DSS/PSS), DMSS Mobile App
Interoperability: ONVIF
Storage: Micro SD Card (Max. 128 GB, Card Not Included)
Audio: 1/1 Audio In/Out (RCA Terminal) — Note: Built-in microphone is not specified in official documentation; audio connectivity is via external audio input/output terminals
Alarm: 1/1 Alarm In/Out
Smart Features: IVS (Face Detection, Tripwire, Intrusion)
Abnormality Detection: Motion Detection, Video Tampering, Network Disconnection, IP Conflict, Illegal Access, Voltage Detection
Power Supply: DC 12V / PoE (802.3af, Class 0) / ePoE
Power Consumption: <5.5 W
Operating Conditions: -40°C to +60°C (-40°F to +140°F)
Protection: IP67 Weatherproof; IK10 Vandal-Proof
Casing Material: Metal
Dimensions: Φ109.9 mm × 81 mm
Net Weight: Not Specified in Available Sources
Certifications: CE (EN 60950:2000); UL (UL60950-1); FCC (Part 15 Subpart B)
Key Specs: Dahua DH-IPC-HDBW4631EP-ASE Eco-savvy 3.0 6MP WDR IR Mini Dome Camera, 1/2.9" 6MP STARVIS CMOS, 3072×2048 @ 20fps, 2.8mm/3.6mm Fixed Lens (F1.6), 30m Smart IR, 120dB True WDR, 3D DNR, H.265+/H.264+ Triple-Stream, IVS (Face Detection/Tripwire/Intrusion), 1/1 Alarm In/Out, 1/1 Audio In/Out, MicroSD up to 128GB, PoE (802.3af) / ePoE / 12V DC, IP67 Weatherproof, IK10 Vandal-Proof, Metal Housing, ONVIF, Φ109.9×81mm
Usage: Outdoor & Indoor Surveillance, Residential Security, Commercial & Retail Monitoring, Parking Lots, Driveways, and Any Installation Requiring a Vandal-Resistant, Weatherproof Dome Camera with High-Resolution 6MP Imaging and Smart Detection Capabilities
