Device Type: 5-Port Unmanaged Fast Ethernet Switch
Model / SKU: Dahua SF1005L5 (also listed as DH-SF1005L)
Ethernet Ports: 5x 10/100 Mbps adaptive RJ45 ports (Ports 1–5: 5 × 10/100 Base-T)
Switching Capacity: 1 Gbit/s
Packet Forwarding Rate: 0.744 Mpps
MAC Table Size: 2K entries
Packet Buffer: 768 kbit
Power Supply: 5 VDC, 1 A (Power adapter included)
Power Consumption: Idling 0.1W / Full load 0.5W
MTBF: 952.50 years
Operating Temperature: 0°C to +45°C
Dimensions / Weight: 86.4 × 52.0 × 23.0 mm; 0.12 kg (net)
Casing: Plastic, fanless, light grey
Installation: Desktop mount (wall-mount supported per some listings)
Certifications: CE
Key Specs: Dahua SF1005L5, 5-Port Unmanaged Fast Ethernet Switch, 5x 10/100 Mbps RJ45, 1 Gbps Switching Capacity, 0.744 Mpps Forwarding, 2K MAC Table, 768 kbit Buffer, 5V DC Adapter Included, Fanless Plastic Housing, 0.12kg, CE Certified
Usage: Expanding wired network connectivity in home offices, small businesses, and CCTV installations. The plug-and-play unmanaged design requires no configuration—simply connect the power adapter and Ethernet cables. Ideal for adding extra LAN ports for IP cameras, NVRs, computers, and other network devices in small setups.
