Multi Angle Wall and Ceiling Mount Bracket - 862-05-512

Device Type: Multi-Angle Swivel Mounting Bracket (for Passive Infrared Detectors)
Model / SKU: FA-3
Brand: OPTEX
Colour: Cream / White / Off-White (regional listings vary)
Function: Provides versatile wall or ceiling mounting for OPTEX PIR motion detectors, allowing precise adjustment of the detector's field of view for optimal coverage.
Compatibility (OPTEX Detector Series):

• Explicitly Listed: RX-40PI, MX-40PI, CX-502, DX-40/60, EX-35, FX-40, CDX-AM, CDX-NAM, CDX-DAM, WNX-40 Series
• Additional Supported Models: RX-40, EX-35, CX-502/502AM, DX-40/60/40PLUS/60PLUS, FX-50, MX-40/50, SQ-40/60, RXC Series, FMX Series
• Not Compatible With: CX-702, LX-402, LX-802N

Adjustment / Articulation:

• Horizontal Rotation: ±45°
• Vertical Tilt: 0° to +10° or 0° to +15° (varies by detector model)
• Multi-Angle Design: Allows both wall and ceiling mounting with flexible orientation

Material: ABS Plastic
Net Weight: 0.1 kg (100 g)
Packaging Dimensions: 55 mm (W) × 65 mm (L) × 55 mm (H)
Key Features:

• Multi-angle swivel head for precise detector aiming
• Reinforced structural support for maximum stability and security
• Modular design adapts to multiple installation configurations
• Quick and precise installation completed in minutes
• High-strength materials resist extreme weather conditions
• Compatible with a wide range of OPTEX PIR detector series

Key Specs: OPTEX FA-3 Multi-Angle Wall & Ceiling Mount Bracket, ±45° Horizontal Rotation / 0–15° Vertical Tilt, ABS Plastic Construction, 0.1kg Net Weight, Compatible with RX-40PI / MX-40PI / CX-502 / DX-40/60 / EX-35 / FX-40 / CDX / FMX / RXC Series Detectors, Not Compatible with CX-702 / LX-402 / LX-802N, Cream/White Colour
Usage: Professional Installation of OPTEX PIR Motion Detectors, Wall or Ceiling Mounting for Optimal Detection Coverage, Residential & Commercial Security Systems, Perimeter Protection, and Any Application Requiring Precise Detector Orientation
