Port Configuration & Application: It features 25 RJ45 ports designed specifically for Category 3 performance, making it ideal for voice, ISDN, and analog telephone applications up to 16 MHz . Typically, only pins 4 and 5 are active in each port to support standard 2-pair, 2-line voice setups .
Termination Style: The rear of the panel features a single female Telco 50-pin (RJ21) connector . This design allows for quick connection of a 25-pair cable and generally does not require a punch-down tool for termination .
Form Factor: It is a flat patch panel that occupies 1 Rack Unit (1 RU) of space, which is approximately 1.75 inches in height . It is designed to mount in standard 19-inch EIA racks or cabinets .
Cable Management & Routing: The panel includes a built-in strain relief bar to secure incoming cables and provide proper support . The Telco connector on the back accommodates patch cords at 180, 110, or 90-degree angles .
Identification & Materials: It includes write-on areas for port identification and can be labeled according to TIA/EIA-606-A standards . The construction typically features powder-coated steel in a black finish for durability .
