10-Meter Low-Loss Coaxial Assembly: This is a factory-terminated 10-meter jumper built with 5D-FB coaxial cable. This cable type is designed to significantly reduce signal loss compared to standard RG-58 cables, making it suitable for connecting antennas, repeaters, and amplifiers where signal integrity over distance is critical .
N-Male to N-Male Connectors: Both ends are equipped with N-type male (N-male) connectors. These threaded connectors provide a secure and reliable connection for RF equipment, commonly found on cellular signal boosters, antennas, and routers .
Optimized for 2G/3G/4G Signal Systems: The assembly is primarily marketed for use in cellular signal amplification systems. The 5D-FB cable and N-type connectors are standard for connecting external antennas to signal boosters or repeaters for improved mobile coverage .
5D-FB Cable Construction: The cable features a Copper Clad Aluminum (CCA) center conductor with a Foamed PE (FPE) dielectric, a double shield (aluminum foil + tinned copper braid), and a PVC outer jacket. It has a nominal outer diameter of 7.5 mm and a characteristic impedance of 50 Ohms .
Typical Part Number Family: The "JP-5D-NJ/NJ" prefix identifies this as a Lintratek-style cable assembly. The "-10" suffix denotes the 10-meter length within this product family (which also includes 5m, 15m, 20m, 30m, etc.)
