KSh 18,400(KSh 21,344 Incl VAT)
Device Type: Large-Capacity PON OLT (Optical Line Terminal) – ZTE ZXA10 C600
Platform: TITAN series, fully-distributed and programmable router architecture
Chassis Options: 11U height; available in 19-inch and 21-inch shelf options
Service Slots: 21-inch: 17 slots; 19-inch: 15 slots
Backplane Capacity: 14 Tbit/s backplane; 7.36 Tbit/s system switching capacity
Per-Slot Bandwidth: 200G per service slot
PON Port Capacity: Up to 272 GPON/XG(S)-PON/Combo PON/Any-PON ports (21-inch chassis); 240 ports (19-inch)
Uplink Interfaces: 16/8 × 10GE per card; 2 × 100GE per card
PON Line Card Options: 16-port GPON; 16-port 10G-EPON; 16-port XG-PON & GPON Combo; 16-port XGS-PON & GPON Combo; 16-port Any-PON
P2P Line Card Options: 16 × 10GE/GE; 24/48 × GE/FE
Redundancy: Power board, main control switch board, uplink ports, fans; Type B/C protection
Power Supply: DC -48V ±20% or -60V ±20%; Max input current 60A
Operating Temperature: -40°C to +65°C (minimum start-up -25°C)
Operating Humidity: 5%–95%
Dimensions (H×W×D): 21-inch: 486.1 × 535 × 288.5 mm; 19-inch: 486.1 × 482.6 × 288.5 mm
Weight: 21-inch empty: 21 kg; 19-inch empty: 18 kg; Full configuration: <58 kg (21-inch) / <52 kg (19-inch)
Key Specs: ZTE ZXA10 C600, TITAN Platform, 14T Backplane, 7.36T Switching, 272 PON Ports, Combo PON, Any-PON, SDN/NFV Ready, 100GE Uplink, Carrier-Grade QoS
Usage: Telecom Operator FTTx Networks, Large Enterprise Campus Networks, Fixed Mobile Convergence (FMC) Deployments, 4K/8K Video and VR Service Delivery, Mobile Backhaul, Hotspot Coverage
