KSh 430(KSh 499 Incl VAT)
Device Type: Fixed Fibre Optic Attenuator (Singlemode)
Brand/Model: Generic — 8dB Fixed Attenuator (brand varies; e.g., Amphenol, Whyte, FCA, GoreLink)
Video Output: N/A
Data Ports: Connector options include SC/UPC, SC/APC, LC/UPC, LC/APC (Male-to-Female plug style)
Attenuation: 8 dB (Nominal)
Attenuation Tolerance: ±0.5 dB (for 1–9 dB range, per most standards) or ±10% of nominal value (Amphenol's ≥6 dB rule)
Operating Wavelength: 1260–1620 nm (broadband) or 1310/1550 nm
Return Loss (Minimum): ≥45 dB (UPC, generic) / ≥50–55 dB (UPC, premium) / ≥60–65 dB (APC)
Max Optical Power: 200 mW (typical) to 300 mW (some models)
Fiber Type: Singlemode (9/125 µm)
Operating Temperature: −40°C to +80°C (varies by brand; some list +85°C storage)
Key Specs: 8dB Fixed Fibre Optic Attenuator, Singlemode, SC/LC Connector Options (UPC/APC), 1260-1620nm, ±0.5dB Tolerance, ≥45dB Return Loss, 200mW Max Power
Usage: Passive Optical Networks (PON), Fibre Distribution Frames, Telecom & Data Centre Links, Preventing Optical Receiver Overload, Signal Balancing in FTTX Systems
