Device Type: Fixed Fibre Optic Attenuator (Singlemode)
Attenuation: 10 dB (Nominal)
Attenuation Tolerance: ±1.0 dB (or ±10%)
Operating Wavelength: 1260 – 1360 nm / 1430 – 1625 nm (or 1310/1550 nm)
Return Loss (Minimum): ≥ 40 dB (LC/UPC) / ≥ 50 dB (SC/UPC) / up to ≥ 65 dB (SC/APC)
Max Optical Power: 250 mW
Fiber Type: Singlemode G.652.D (9/125 µm)
Connector Options: LC/UPC, SC/UPC, SC/APC, FC/UPC (Male-to-Female or Build-Out style)
Operating Temperature: −40°C to +75°C (varies slightly by manufacturer)
Key Specs: 10dB Fixed Fibre Optic
Attenuator, Singlemode, LC/SC/FC Connector Options, 1260-1625nm Wavelength, ±1dB Tolerance, ≥40dB Return Loss, 250mW Max Power
Usage: Passive Optical Networks (PON), Fibre Distribution Frames, Telecom & Data Centre Links, Preventing Optical Receiver Overload, Signal Balancing
