Core Specifications and Features
Power and Output
- Capacity: 1500VA / 900W, power factor 0.6 .
- Topology: Line-interactive, providing pure sine wave output during battery operation, compatible with active PFC power supplies .
- Output Sockets: 8× IEC C13 (plus 2 IEC jumpers), input interface is IEC C14 .
- Transfer Time: Typically 6 ms, maximum 10 ms .
Voltage Regulation and Protection
- AVR (Automatic Voltage Regulation): Corrects mains voltage fluctuations without switching to battery, extending battery life .
- Input Voltage Range: 170–300V adjustable (default 180–287V) .
- Surge Protection: 459 Joules surge energy rating .
Monitoring and Management
- LCD Display: Multifunction graphical LCD status and control console for real-time viewing of load, battery, and status information .
- SmartConnect Port: Ethernet port supporting cloud-based remote power monitoring, accessible via QR code registration from any internet-connected device .
- Communication Interfaces: Serial port + USB port, combined with PowerChute software for graceful shutdown .
Battery and Physical
- Battery Type: Internal sealed lead-acid battery, replaceable model RBC6, charging time 3 hours, expected lifespan 3–5 years .
- Dimensions and Weight: 219 × 171 × 439 mm, weighing 20.1 kg, tower placement (not rack-mountable) .
- Operating Environment: 0–40°C, noise level approximately 45 dBA .
