Device Type: Three-Phase Online Double-Conversion Tower UPS (Uninterruptible Power Supply)
Part Number/SKU: G3HT60KHB2S
Brand: APC by Schneider Electric (MGE Galaxy 300 Series)
Power Rating: 60 kVA / 54 kW (Output Power Factor 0.9)
Topology: True Online Double-Conversion
Phase Configuration: 3:3 (3-Phase Input / 3-Phase Output)
Input:- Main Input Voltage: 400 V AC 3-Phase (Configurable 380 V / 415 V)
- Input Voltage Range: 340–477 V AC (Adjustable)
- Input Frequency Range: 45–65 Hz
- Maximum Input Current: 228 A
- Input Power Factor at Full Load: 0.99
- Input Harmonic Distortion: <5% at Full Load
Output:- Main Output Voltage: 400 V AC 3-Phase (Configurable 380 V / 415 V)
- Output Voltage Tolerance: ±2% (Static and 100% Load Step)
- Output Harmonic Distortion: <3% (Linear Load) / <5% (Non-Linear Load)
- Output Frequency: 50/60 Hz (Sync to Mains); 50/60 Hz ±1 Hz (Unsynchronized)
- Load Power Factor: 0.5 Leading to 0.5 Lagging
- Crest Factor: 3:1
- Overload Capability: 10 Minutes at 125%; 30 Seconds at 150%
- Output Connection: Hard Wire 5-Wire (3P + N + E)
- Bypass Type: Built-In Static Bypass
Battery:- Battery Type: Lead-Acid, Internal
- Battery Voltage: ±192 V DC (Split Battery Referenced to Neutral)
- Discharge Battery Voltage: ±154 V
- Included Battery Runtime: 10 Minutes at Full Load
- Battery Life: 3–5 Years
- Extended Runtime Capability: Supports External Battery Cabinets for Up to 4 Hours Runtime
Display & Communication:- Control Panel: Multifunction LCD Status and Control Console
- Network Management: Network Management Card Included
- USB Compatible: No
- Emergency Power Off (EPO): Yes
Physical & Environmental:- Form Factor: Free-Standing Tower
- Dimensions (H × W × D): 1900 × 700 × 950 mm
- Net Weight: 735 kg
- Mounting Preference: No Preference
- Operating Temperature: 0°C to 40°C
- Relative Humidity: 0–95%
- Operating Altitude: Up to 3000 ft
- Protection Rating: IP20
Included Equipment:- CD with Software
- Dust Filter
- Installation Guide
- Network Management Card
- Start-Up Service (5x8)
- User Manual
Compliance & Certifications: CE, EAC; EN/IEC 62040-1, EN/IEC 62040-2, EN/IEC 62040-3, ISTA 2B, IEC 62040-4
Product Status: Discontinued on 31 December 2019 — End-of-Service on 18 October 2023
Key Specs: APC Galaxy G3HT60KHB2S, 60kVA/54kW Three-Phase Online Double-Conversion UPS, 3:3 Phase, 400V AC (380/415V Configurable), 340–477V AC Input Range, 45–65Hz, Input PF 0.99, Output THD <3% Linear, ±192V DC Internal Lead-Acid Battery, 10 Min Runtime at Full Load (Extendable to 4 Hours), Hard Wire 5-Wire Output, Built-In Static Bypass, Multifunction LCD, Network Management Card Included, EPO, 1900×700×950mm, 735kg, Discontinued Product
Usage: Small Data Centers, Commercial Buildings, Technical Facilities, and Mission-Critical Applications Requiring High-Capacity Three-Phase Power Protection with Internal Battery Backup and Extended Runtime Capability
