Total Rate up to 6.45 Gbps: Delivers 0.69 Gbps on the 2.4 GHz band and 5.76 Gbps on the 5 GHz band for ultra-fast wireless connectivity .
Wi-Fi 7 Technologies: Supports MLO (Multi-Link Operation) for dual-band aggregation, 4096-QAM modulation for 20% higher throughput than Wi-Fi 6, and 160 MHz channel width .
Dual-Band Configuration: Operates on 2.4 GHz (2x2 MIMO) and 5 GHz (4x4 MIMO) simultaneously .
Smart Antenna Coverage
Built-in Smart Antennas: Automatically adjusts signal direction and strength based on environmental conditions to optimize coverage without manual intervention .
30 m Optimal Coverage Radius: Provides reliable wireless coverage for typical office spaces and high-density areas .
High-Density Capacity
160 Recommended Users: Optimized for concurrent connections in busy environments, with a maximum capacity of 1,024 users .
Up to 10 SSIDs per Radio: Enables advanced network segmentation for different departments or guest networks .
Connectivity and Power
2.5GE Uplink Port: High-capacity wired backhaul with 2.5 Gbps full-duplex support .
Secondary Gigabit Port: Additional 10/100/1000M Ethernet port for flexible wired connectivity .
PoE 802.3at/af Support: Powered via Ethernet cable, simplifying installation where power outlets are unavailable .
USB Port: Integrated USB interface for additional connectivity or expansion .
Management and Security
Multiple Management Options: Local management via EasyWeb or WAC controller; remote management via Huawei eKit App and SME Cloud Platform .
Advanced Security: Supports WPA3, WPA2, 802.1X authentication, and encryption for enterprise-grade protection .
Seamless Roaming: Intelligent roaming technology prevents connection stickiness as users move between APs .
Physical Design
Compact Round Form Factor: 220 mm diameter x 45 mm depth, designed to blend into office ceilings and walls .
Flexible Mounting: Supports ceiling, wall, and rail mounting with durable metal bracket .
