Device Type: External Battery Module (EBM) for Eaton 9E Series UPS
Part Number/SKU: 9EEBM240 (also available as 9EEBM240R for the Rack 3U variant)
Brand: Eaton (9E Series)
UPC: 743172067746
Compatibility: Designed specifically for Eaton 9E Series UPS systems. Compatible models include:
- 9E10Ki / 9E10KiXL (10 kVA)
- 9E15Ki / 9E15KiXL (15 kVA)
- 9E20Ki / 9E20KiXL (20 kVA)
- Also compatible with Eaton 5125 and 9125 UPS systems
Battery System:- Battery Type: Sealed, Lead-Acid (VRLA), Maintenance-Free
- Battery Quantity: 40 × 12 V / 9 Ah Blocks
- System Voltage: 240 V DC
- Battery Management: Automatic Battery Test, Deep Discharge Protection
- Extended Runtime Capability: Yes — Up to 4 EBMs can be connected to a single UPS for extended runtime
- Runtime Impact: The EBM 240 can provide up to 4× the battery runtime of the internal batteries in the UPS
Physical Specifications:- Form Factor: Tower (Free-Standing, on Castors); 9EEBM240R variant is Rack 3U
- Dimensions (L × W × H): 26.24 × 57.94 × 70.85 cm
- Weight: 131.94 kg
- Colour: Black
Included Accessories: Extended Battery Module (EBM) and Quickstart Guide
Compliance & Certifications: CE Marked, TUV; IEC/EN 62040-1, IEC/EN 62040-2, CE, EAC
Warranty: 2 Years
Key Specs: Eaton 9EEBM240 External Battery Module for Eaton 9E Series UPS, 240V DC System, 40 × 12V/9Ah Sealed Lead-Acid Batteries (Maintenance-Free VRLA), Automatic Battery Test, Deep Discharge Protection, Extends Runtime Up to 4× Internal Batteries, Supports Up to 4 EBMs per UPS, Tower Form Factor (Castors) or Rack 3U (9EEBM240R), 131.94 kg, 2-Year Warranty
Usage: Extending Backup Runtime for Eaton 9E Series UPS Systems (9E10Ki, 9E15Ki, 9E20Ki and XL variants) in Data Centers, Server Rooms, Telecommunications, and Mission-Critical Applications Requiring Extended Power Availability During Prolonged Outages
