KSh 275,870(KSh 320,009 Incl VAT)
Warranty: 1 Year
Device Type: 75" Smart Interactive Whiteboard / Interactive Flat Panel (DeepHub Pro Series)
Brand/Model: Dahua DHI-LPH75-ST470-P
Video Output:
Panel Size: 75-inch
Resolution: 4K UHD (3840 × 2160), 16:9 Aspect Ratio
Backlight: DLED (Direct-lit LED)
Brightness: 400 cd/m² (Typ.)
Contrast Ratio: 4000:1 (VA) / 1200:1 (IPS)
Viewing Angle: 178° (H) / 178° (V)
Response Time: 8 ms (Typ.)
Refresh Rate: 60 Hz
Display Color: 1.07B / 10-bit (8-bit + FRC)
Lifespan: 50,000 hours
Data Ports:
Front Ports: 1× USB-C (4K@60Hz, Touch, 65W PD), 1× HDMI In (4K@60Hz), 1× USB 3.0 Type-B (Touch), 2× USB 3.0 Type-A, 1× Mic In (3.5mm)
Rear Ports: 1× USB-C (4K@60Hz, Touch, 15W), 2× HDMI In (4K@60Hz), 1× VGA In (1080p@60Hz), 1× DP In (4K@60Hz), 3× USB 3.0 Type-B (Touch), 1× HDMI Out, 2× USB 3.0 Type-A, 1× USB 2.0 Type-A, 1× Micro USB, 1× RS-232, 1× RJ-45 In, 1× RJ-45 Out, 1× Audio In, 1× Audio Out, 1× SPDIF Out (Optical), 1× OPS Slot
Built-in System:
Operating System: Android 11
CPU: Quad-core A73 + Quad-core A53 (2.2GHz + 2.0GHz)
GPU: ARM Mali-G52 MP8
RAM: 8 GB
ROM: 64 GB (Optional 128 GB)
Touch & Writing:
Touch Technology: Infrared (IR)
Attachment Method: Zero Air Gap
Touch Points: Android 32 / Windows 40
Response Time: ≤10 ms
Touch Accuracy: ±1 mm (over 90% area)
Valid Touch: 2 mm
Surface: 4 mm Anti-dazzle Tempered Glass, 8H Hardness
Writing Mode: Finger + Stylus Pen (2 passive pens included)
Audio & Microphone:
Speakers: 2.1 Channel — Front 2× 15W (Max) + Rear 20W (Max)
Microphone: 8-Array, Pick-up Distance 6m–10m
Audio Features: AGC, Echo Cancellation, Intelligent Noise Filtering, Omni-directional
Power & Environment:
Power Supply: 100–240 VAC, 50/60 Hz
Power Consumption: 150W (Typical) / 350W (Maximum); Standby ≤0.5W
Operating Temperature: 0°C to +40°C
Storage Temperature: –10°C to +50°C
Physical & Build:
Mounting: Wall Mount (bracket pre-installed) or Mobile Bracket
Casing: Metal Housing + 4mm Anti-dazzle Tempered Glass
Dimensions (W×D×H): 1,707.5 × 93.0 × 1,050.0 mm
Net Weight: 54 kg / Gross Weight: 68 kg
VESA Holes Distance: 600 × 400 mm
Key Specs: Dahua DHI-LPH75-ST470-P, 75" 4K UHD (3840×2160) Smart Interactive Whiteboard, Android 11, Octa-Core (A73+A53), 8GB RAM / 64GB ROM (Expandable to 128GB), Infrared Touch (32/40 Points), Zero Air Gap, 400 nits, 8-Array Microphone (6–10m), 2.1Ch Speakers (2×15W + 20W), 4K@60Hz HDMI/DP/USB-C (65W PD), Dual RJ45, Wi-Fi 5 + Wi-Fi 6 AP, Bluetooth 5.2, OPS Slot for Windows, Metal Housing, Wall Mount
Usage: Classrooms & Lecture Halls, Corporate Boardrooms, Training Rooms, Conference Centers, Interactive Presentations, Collaborative Meetings, Hybrid Work & Video Conferencing, Digital Signage with Touch Interaction
