Device Type: 32U Freestanding Server / Network Cabinet (19-inch Standard)
Part Number/SKU: 32U 600x800 (Easenet Data Cabinet Series)
Brand: Easenet
Rack Capacity: 32U
Standard: 19-inch EIA / ETSI Compatible; Complies with ANSI/EIA RS-310-D, DIN41491 Part 1, IEC297-2, DIN41494 Part 7, GB/T3047.2-92
Dimensions (W × D): 600 mm × 800 mm
External Height: Approximately 1600 mm (varies slightly by configuration)
Front Door: Tempered Glass Door with Over 180° Turning Degree, Lockable
Rear Door: Swing Back with Over 90° Turning Degree, Lockable
Side Panels: Removable Side Panels, Easy to Install and Maintain (Lock Optional)
Material & Construction:- Material: SPCC Cold Rolled Steel; Zinc Plated Mounting Profiles
- Thickness: Mounting Profile: 1.0 mm; Other Components: 0.6 mm
- Surface Finish: Degreasing, Pickling, Phosphating, Powder Coating
- Structure: Steel Frame with Assistant Profile, Double Section
Load Capacity (Static): Not explicitly specified for this Easenet model; comparable 32U 600x800 cabinets in this class typically support 800–1000 kg
Protection Rating: IP20
Ventilation: Fan Cutout on Top, Easy to Install Fan; Vents at Top and Bottom for Natural Airflow; Optional Fan Kits Available
Cable Management: Cable Entry on Top and Bottom; L-Shaped Mounting Profile, Easy to Adjust on Mounting Rail; Tie Points Inside for Reduced Clutter
Mounting: Adjustable 19-inch Vertical Rails with U Position Markings; Free-Standing with Adjustable Feet or Optional Wheels
Colour: RAL9004 (Black) or RAL7035 (Grey White)
Grounding: Integrated Grounding Points for Equipment Protection
Optional Accessories: PDU, Fan, Shelf, Bracket, Cable Tray, Cabinet Lock, Cabinet Tray
Certification: ISO 9001:2000; OEM/ODM Service Available
Key Specs: Easenet 32U Freestanding Server Rack Cabinet, 600×800mm (W×D), 19-inch EIA/ETSI Compatible, Tempered Glass Lockable Front Door (Over 180°), Lockable Rear Door (Over 90°), Removable Side Panels, SPCC Cold Rolled Steel Construction, Zinc Plated Mounting Profiles (1.0mm), IP20 Rating, Fan-Ready Top Cutout, Top & Bottom Cable Entry, Adjustable 19-inch Rails with U Markings, Integrated Grounding, Black (RAL9004) or Grey (RAL7035) Finish
Usage: Small, Medium and Large Servers; DVR & Security Equipment; Routers & Switches; Patch Panels; Telephone Systems & PABX; Network & Communications Equipment; UPS Equipment; Other Rack Mount Equipment. Ideal for medium-sized networks, data centers, server rooms, telecom, and surveillance equipment requiring deeper cabinet space for longer devices and improved cable routing.
