Device Type: Line-Interactive Tower UPS (Uninterruptible Power Supply)
Part Number/SKU: 5E1500iUSB (Also available as 5E1500IUSB-TH for the Thai market, and 5E1500IUSB-AU for Australia/New Zealand)
Brand: Eaton (5E Series)
Power Rating: 1500 VA / 900 W
Topology: Line-Interactive
Output Waveform: Modified Sine Wave (Stepped Approximation)
Input:- Nominal Voltage: 230 V AC
- Input Voltage Range: 170–280 V AC
- Input Frequency Range: 50/60 Hz Auto-Sensing
- Input Connection: IEC C14 (10A)
Output:- Nominal Voltage: 230 V AC
- Voltage Regulation (Battery Mode): ±10%
- Frequency Regulation (Battery Mode): ±1 Hz
- Outlets: 6 × IEC C13 (Battery Backup & Surge Protection)
- Transfer Time: 4–8 ms Typical, 10 ms Maximum
Battery:- Battery Type: Sealed Lead-Acid (SLA), Maintenance-Free
- Battery Configuration: 2 × 12V / 9Ah
- Recharge Time: Approximately 6 Hours to 90% Capacity
- Runtime (100W Load): Up to 40 Minutes
- Runtime (Full Load): Approximately 5–10 Minutes (varies by device)
- Battery Management: Automatic Battery Test, Deep-Discharge Protection, Overcharge Protection, Cold-Start Capable
Communication & Software:- Port: 1 × USB (HID Compliant)
- Software: Eaton UPS Companion (for safe system shutdown, energy metering, and UPS configuration)
- User Interface: LED Status Indicators
Surge & Data Line Protection: Yes — Data line surge protection for Internet/Tel/Fax connections
Physical & Environmental:- Form Factor: Free-Standing Tower, Black
- Dimensions (H × W × D): 180 × 133 × 330 mm
- Weight: 10.5 kg (Net)
- Operating Temperature: 0°C to 40°C
- Noise Level: Less than 45 dB at 1 Meter
- Maximum Operating Altitude: 2,000 m
Compliance: IEC/EN 62040-1, IEC/EN 62040-2, CE Marked
Key Specs: Eaton 5E1500iUSB, 1500VA/900W Line-Interactive Tower UPS, AVR, Modified Sine Wave Output, 6× IEC C13 Outlets, IEC C14 Input, 170–280V Wide Input Range, 4–8ms Transfer Time, 2× 12V/9Ah Sealed Lead-Acid Battery, 6-Hour Recharge, USB (HID) Communication, Eaton UPS Companion Software, Data Line Surge Protection (Internet/Tel/Fax), LED Indicators, <45dB Quiet Operation, 10.5kg, 2-Year Warranty
Usage: Home & Home Office PCs, Workstations, Small Servers, Network Switches & Routers, CCTV Systems, Point-of-Sale (POS) Terminals, Retail Stores, and Small Business IT Environments. Provides protection against power outages, voltage fluctuations, surges, and spikes.
