Device Type: 50m Active Optical HDMI Cable (AOC)
Brand/Model: Generic – 50M AOC HDMI Cable (brand varies; e.g., Black Box AOC-HL-H2-50M, ACT AK4106, Gembird CCBP-HDMI-AOC-50M-02, Canford AO-HD-A50, Delock 86034)
Video Output: HDMI Type-A Male to HDMI Type-A Male; supports up to 4K UHD (4096×2160 / 3840×2160) @ 60Hz 4:4:4 on HDMI 2.0 variants; HDMI 2.1 variants support up to 8K @ 60Hz / 4K @ 144Hz
Data Ports: HDMI Type-A connectors; supports EDID / DDC / CEC / HEC (HDMI Ethernet Channel); ARC (Audio Return Channel) supported
Bandwidth: 18 Gbps total (HDMI 2.0); 48 Gbps on HDMI 2.1 variants
Resolution & Refresh: HDMI 2.0: 4K @ 60Hz (4:4:4), 1080p, 3D; HDMI 2.1: 8K @ 60Hz, 4K @ 144Hz
HDCP & HDR: HDCP 2.2 compliant; supports HDR (High Dynamic Range)
Audio Support: Multi-channel audio, PCM, DTS-HD Master Audio, Dolby Digital True HD; supports up to 32 audio channels with 1536 kHz sampling on some models
Cable Construction: Hybrid fiber + copper design; Kevlar-protected fiber; aluminium foil shielding; low RFI/EMI profile
Power Requirement: No external power required – bus-powered via HDMI connector (optional USB power cable included on some models for low-power HDMI ports)
Bend Radius: 45 mm (standard flexible models) or 20 mm (armoured high-flex models)
Jacket Options: TPU (standard flexible), PVC, or LSZH (Low Smoke Zero Halogen) depending on model
Operating Temperature: −40°C to +70°C (armoured/harsh-environment models)
Key Specs: 50m Active Optical HDMI Cable (AOC), HDMI 2.0 (4K@60Hz/18Gbps) or HDMI 2.1 (8K@60Hz/48Gbps), HDCP 2.2, HDR Support, Hybrid Fiber+Copper, Kevlar Reinforced, No External Power, 20–45mm Bend Radius, TPU/PVC/LSZH Jacket, −40°C to +70°C
Usage: Long-Distance AV Signal Distribution, Digital Signage & LED Walls, Conference Room & Auditorium Displays, Medical Imaging Equipment, Home Theatre & Projector Setups, Broadcast & Post-Production, Security Monitoring Systems, Live Events & Staging
