KSh 1,000(KSh 1,160 Incl VAT)
Device Type: 5-Meter Coaxial Antenna Cable (RF Extension Cable)
Video Output: N/A (RF signal cable; video capability depends on the connected device)
Data Ports / Connectors: Varies by application – common options include SMA (Male/Female), RP-SMA (Male/Female), N-Type (Male/Female), BNC, FME, and TNC
Impedance: 50 Ohm (typical for cellular, Wi-Fi, and RF applications) or 75 Ohm (typical for TV/SAT applications)
Cable Type / Construction: Varies significantly – common types include RG-58 (standard, flexible), HDF-195 / LMR-200 / CFD200 (low-loss), LMR300 / CFD300 (ultra-low-loss), and LLC200A
Shielding: Double-shielded or triple-shielded with aluminium foil and braid; shielding effectiveness often >90 dB
Attenuation: Dependent on cable type and frequency. Examples:
HDF-195: 0.39 dB/m @ 1 GHz
RG-58: 0.4 dB/m @ 500 MHz
CFD200: 0.55 dB/m @ 2.4 GHz
LMR300 / CFD300: 0.31 dB/m @ 2 GHz
LLC200A: 1.06 dB/m @ 2 GHz
Operating Temperature: Commonly −40°C to +85°C (varies by jacket material)
Jacket Material: PVC (standard indoor), PE (UV-resistant for outdoor), or LSZH (Low Smoke Zero Halogen for fire-sensitive environments)
Key Specs: 5-Meter Coaxial Antenna Cable, 50Ω (Cellular/Wi-Fi) or 75Ω (TV/SAT), Connector Types Vary (SMA/RP-SMA/N-Type/BNC/FME/TNC), Low-Loss Options Available (HDF/LMR/CFD Series), Double/Triple Shielded (>90 dB), Attenuation Varies by Cable Type, −40°C to +85°C, PVC/PE/LSZH Jacket
Usage: Extending Antenna Connections for Cellular/4G/5G Modems & Routers, Wi-Fi Access Points & Adapters, TV/SAT Signal Distribution, RF Test & Measurement, Two-Way Radio & Scanner Antennas, GPS & IoT/M2M Applications
