KSh 4,290(KSh 4,976 Incl VAT)
Device Type: Cat6 UTP 24-Port Loaded Patch Panel (1U Rackmount)
Ports: 24× RJ45 ports, pre-loaded with six-port RJ45 modules
Category / Performance: Cat6 UTP, compliant with ANSI/TIA/EIA-568-C.2 and ISO/IEC 11801
Rack Height: 1U (also available in 2U for higher port counts)
Connector Type: RJ45 female jacks
Termination: IDC terminals suitable for 22–26 AWG stranded and solid wire; compatible with both 110 and Krone punch-down tools
Wiring Scheme: Supports T568A and T568B wiring configurations
Panel Material: SPCC steel, 1.5 mm thickness, black (RAL 9005) powder-coated finish
Jack Housing Material: ABS, UL 94V-0; contact brackets: PC, UL 94V-2
Contact Material: Phosphor bronze with nickel plating; 50 micro-inches gold plating on plug contact area
IDC Material: PC + glass fiber housing (UL 94V-2); phosphor bronze terminals with tin plating
PCB Material: FR4, UL 94V-0
Identification: Transparent PVC ID plate with paper strip; ID stripes for port allocation
Operating Temperature: -10°C to 60°C (per ISO/IEC 11801 and ANSI/TIA/EIA-568-B.2)
Mating Cycles: 750 cycles minimum (jack) per IEC 60603-7-4
Insertion Force: 20N max (IEC 60603-7-4)
Retention Strength: 7.7 kg between jack and plug
Cable Management: Improved cable management with optional cable management bar
Key Specs: D-Link NPP-C61BLK241 Cat6 24-Port Loaded Patch Panel, 1U rackmount, 24× RJ45, 110/Krone compatible, 22–26 AWG IDC, SPCC steel panel, T568A/B, ANSI/TIA/EIA-568-C.2 compliant, gold-plated contacts, 750 mating cycles
Usage: Structured cabling in server rooms, network closets, data centers, telecom rooms, and enterprise LAN/WAN installations requiring Cat6 UTP patching and cable organization
