Device Type: 48-Port Modular Shielded Patch Panel (Empty Frame)
Part Number/SKU: CP48BLY (Standard); CP48WSBLY (with Built-In Strain Relief Bar)
Brand: Panduit (Mini-Com® / Pan-Net® Series)
Port Capacity: 48 Ports
Rack Units: 2 RU
Patch Panel Style: Flat
Module Type: Accepts up to 48 Mini-Com® Shielded Jack Modules (Modules Sold Separately)
Material: Stainless Steel (Panel); ABS Plastic (Faceplates); Phosphor Bronze (Bonding Strip)
Colour: Black
Shield Type: Shielded (STP)
Dimensions:- Overall Width: 19 in (482.6 mm)
- Overall Height: 3.47 in (88.1 mm)
- Overall Depth: 0.7 in (17.8 mm)
- Strain Relief Model Depth: 3.38 in (85.9 mm)
Mounting: Standard TIA/EIA 19" Rack or 23" Rack with Optional Extender Bracket
Standards: RoHS Compliant
UPC: 074983036424 (CP48BLY); 074983036448 (CP48WSBLY)
Features:- Designed for Shielded Installations – Mini-Com® Shielded Jack Modules bond to the metal panel, helping provide a properly grounded system
- Grounding Lugs Included
- White Write-On Areas for Port Identification
- Can Be Identified with Adhesive Labels
- Built-In Strain Relief Bar (CP48WSBLY Model Only)
- CPT Removal Tool Allows Easy Moves, Adds, and Changes of Shielded Jack Modules
Key Specs: Panduit CP48BLY Mini-Com® 48-Port All Metal Shielded Modular Patch Panel, 2 RU, Flat Design, Stainless Steel Construction, Black, Accepts 48 Mini-Com® Shielded Jack Modules, Grounding Lugs Included, White Write-On Areas, 19" and 23" Rack Compatible, RoHS Compliant
Usage: Structured Cabling Installations, Shielded Network Deployments, Data Centers, Enterprise Server Rooms, Telecommunications Rooms, High-EMI Environments, Secure Government & Financial Networks, Any Installation Requiring Shielded Connectivity with Modular Flexibility
