42U(800*1000mm)floor mount rack (mesh door) - NFR-42U-8010-BL-MS

Device Type: 42U Freestanding Server / Network Cabinet (19-inch Standard)
Part Number/SKU: Varies by Brand (e.g., DIGITUS DN-31128, Legrand Nexpand 446451, Excel Environ DCR800, Prism Pi Co-Location Cabinet, Unilink UFR-42U-8010-BL-MS)
Brand: Varies (DIGITUS, Legrand, Excel, Prism, Unilink, Roline, Lanberg, and others)
Rack Capacity: 42U
Standard: 19-inch EIA / DIN 41494 Compatible
Dimensions (W × D): 800 mm × 1000 mm
External Height: Typically 2031 mm – 2053 mm (varies by model; e.g., DIGITUS 2053mm, Legrand 2000mm, DIGITUS varioFLEX 2031mm)
Front Door: Lockable Mesh / Perforated Door

• Mesh Perforation: Typically 70% open area for high airflow and cooling efficiency
• Locking: Swiveling lever handle with 1-point locking mechanism, prepared for profile half-cylinder lock
• Door Opening Angle: 120° on front and rear doors
• Legrand Nexpand: 80% perforated front and double rear doors for advanced airflow management

Rear Door: Lockable Perforated / Mesh Steel Door

• Provides passive ventilation and easy cable access
• Split rear door on some models (e.g., DIGITUS Unique Series)

Side Panels: Removable & Lockable Steel Panels

• Lockable and removable for easy servicing
• Note: Some Legrand Nexpand models are supplied without side panels

Material & Construction:

• Frame: Steel sheet material up to 1.5 mm thick for stability
• Structure: Robust steel construction with special plate curving technique
• Finish: Powder-coated; Grey (RAL 7035) or Black (RAL 9005)
• Legrand Nexpand: Demountable aluminium frame

Load Capacity (Static): 800 kg – 1500 kg (Varies significantly by brand and construction)

• 800 kg: DIGITUS Unique Series, Luggar HI42U-800x1000, Lanmaster TWT-CBB-42U-8X10-G1
• 1500 kg: Legrand Nexpand / Linkeo (demountable aluminium frame)

Protection Rating: IP20 (Standard for Indoor Use)
Ventilation:

• Roof: Special roof construction with added lid containing air ventilation slots for better air circulation
• Fan-Ready: Roof is prepared for mounting an air ventilation unit (fan tray)
• High-Airflow: 70–80% perforated doors provide excellent passive cooling

Cable Management:

• Base: Sliding cable entry panel with rubber sealing
• Rear: Two cable entries with brush strips above and below the door (models from 26U)
• 800mm Width Advantage: Additional cable entries with brushes left and right in the top and base chassis (800mm width models only)
• Vertical Cable Ducts: Mounted with shutters left and right of the 19" profile rails in the front (800mm width models only)

Mounting:

• Profile Rails: 2 pairs (4 pieces) of 483mm (19") profile rails, galvanized with height unit marking (countable from both directions)
• Depth Adjustment: Variable in depth and connected with additional depth support bars
• Equipment Mounting Depth: Min.–Max. 688–943 mm
• Leveling Feet: 4 pieces pre-configured under the rack

Included Accessories (Typical):

• Installation Set: 36 × screws, 36 × captive nuts, 36 × washers
• Adapter: For profile half-cylinder lock
• Grounding Cables: 4 × grounding cables (incl. nuts and washers)
• Leveling Feet: 4 pieces

Key Specs: 42U Freestanding Mesh Network Cabinet, 800×1000mm (W×D), 19-inch EIA/DIN 41494 Compatible, Lockable Mesh Front & Rear Doors (70–80% Perforation), Removable Lockable Side Panels, Steel Construction (up to 1.5mm), Static Load 800–1500 kg, IP20 Rating, High-Airflow Passive Cooling, Fan-Ready Roof, Brush Cable Entries (Top/Bottom/Rear), Vertical Cable Ducts (800mm Width Models), Adjustable 19-inch Rails (688–943mm Mounting Depth), Levelling Feet & Grounding Kit Included, Grey (RAL 7035) or Black (RAL 9005) Powder Coated Finish
Usage: Housing Servers, Network Switches, Patch Panels, Routers, and Telecom Equipment in Data Centers, Enterprise Server Rooms, and Office Comms Rooms. The mesh door design provides superior airflow (70–80% perforation) for high-density equipment, making it ideal for high-performance and continuous 24/7 operations. The 800mm width and 1000mm depth provide extra space for deeper server equipment, enhanced cable management, and efficient airflow management.
