KSh 3,320(KSh 3,851 Incl VAT)
Device Type: 360° Ceiling-Mount Passive Infrared (PIR) Motion Detector
Detection Range: 8m to 12m diameter, depending on mounting height (typically higher ceiling equals wider coverage)
Viewing Angle: 360° full coverage, eliminating blind spots common with wall-mounted detectors
Mounting Height: Typically 2.4m to 4.2m (some models support up to 4m)
Sensor Element: Dual-element or quad-element pyroelectric infrared sensor
Lens Design: Spherical lens or precision optical design for uniform sensitivity across the detection area
Pulse Count: Selectable 2 or 3/4 pulse count via DIP switch to adjust sensitivity and reduce false alarms
Temperature Compensation: Digital or automatic temperature compensation to maintain detection stability in varying environments
RFI/EMI Protection: High immunity to radio frequency interference (e.g., 20V/m from 100MHz to 1GHz)
Alarm Output: Normally Closed (N.C.) relay output (rating varies, e.g., 28VDC 0.2A max)
Tamper Protection: Normally Closed tamper switch that opens when the cover is removed
Operating Voltage: Typically 9.5–18VDC (varies by model)
Current Draw: Approximately 17mA (normal) to 18mA (max)
Operating Temperature: -20°C to +50°C (varies slightly by model)
Ideal Applications: Warehouses, retail shops, and large open areas where shelving or obstructions may block standard wall-mounted PIR detectors
