KSh 860(KSh 998 Incl VAT)
Device Type: Telephone Distribution Box / Disconnect Terminal Block (VDF/Krone style)
Capacity: 30 Pairs (30回线)
Housing Material: Flame-retardant ABS or PBT plastic
Contact Material: Silver-plated phosphor bronze or copper alloy
Contact Resistance: ≤ 7 mΩ (between disconnected terminals); ≤ 3 mΩ (after termination)
Insulation Resistance: ≥ 1000 MΩ
Pull-out Force: ≥ 25 N (for 0.4mm wire)
Termination Lifespan: ≥ 200 cycles
Operating Temperature: 5°C to 40°C (varies by manufacturer)
Relative Humidity: < 85% (at 30°C)
Compatibility: Krone LSA-PLUS style modules; can accept surge protection units for over-voltage/over-current protection
Mounting Options: Wall-mounted or rack-mounted (19-inch, often 1U height for 30-pair units)
Typical Applications: Telephone voice cabling, small PBX systems, indoor cable cross-connection, and low-voltage distribution nodes
