EVO 200kVA 4-slot modular UPS cabinet

Device Type: Modular UPS Cabinet (4-Slot, Empty/Configurable)
Nominal Capacity: 200kVA (maximum configurable, using 4 × 50kVA modules)
Module Slots: 4 Slots (each rated for 50kVA power modules)
Input: 3-Phase, 380/400/415V AC, 50/60Hz
Output: 3-Phase, 380/400/415V AC, 50/60Hz, Power Factor 1.0
Topology: Online Double Conversion (VFI-SS-111)
Bypass: Built-in Electronic Bypass + Manual Maintenance Bypass
Communication: RS-232, RS-485, USB, Dry Contact, SNMP Slot (varies by model)
Display: Touchscreen LCD (typically 7-inch)
Protection Rating: IP20
Typical Cabinet Dimensions: Approx. 600 × 850 × 1600 mm (varies by manufacturer)
Key Specs: 200kVA Modular UPS Cabinet, 4x 50kVA Module Slots, Online Double Conversion, 3-Phase Input/Output, Hot-Swappable Modules, Integrated Maintenance Bypass, Scalable N+X Redundancy, IP20
Usage: Medium/Large Data Centers, Enterprise Server Rooms, Telecommunications Infrastructure, Critical Power Protection, Scalable UPS Deployments
