KSh 430(KSh 499 Incl VAT)
Device Type: 1×2 PLC Fiber Optic Splitter (ABS Box Module)
Configuration: 1 Input × 2 Output Ports
Connector Type: SC/UPC (Standard, based on "UPS" designation)
Fiber Type: Single-Mode G.657A1 (Bend-Insensitive)
Operating Wavelength: 1260–1650 nm
Insertion Loss: ≤ 4.2 dB (Max, with connectors)
Uniformity: ≤ 0.4 dB (Max)
Return Loss: ≥ 50 dB (UPC)
Polarization Dependent Loss (PDL): ≤ 0.2 dB
Directivity: ≥ 55 dB
Operating Temperature: -40°C to +85°C
Packaging: ABS Box Module (Standard size ~100 × 80 × 10 mm)
Pack Quantity: 50 Pieces per Tie/Pack
Key Specs: 1×2 PLC Splitter, SC/UPC Connectors, G.657A1 Single-Mode, 1260–1650nm, ≤4.2dB Insertion Loss, ≥50dB Return Loss, ABS Box, 50pcs per Pack
Usage: FTTH/FTTx Networks, GPON/EPON Passive Optical Networks, Optical Distribution Boxes, Network Cabinets, CATV Systems
