Device Type: Pure Sine Wave Inverter / Battery Charger (Transformer-Based)
Model: Shield X1-12048
Brand: Shield (Magnizon)
System Capacity: 12KW (12,000 Watts)
Battery System: 48V DC Nominal (48VDC)
Output Waveform: Pure Sine Wave (Same as Input in Bypass Mode)
Surge Rating: 3x Rated Power (36KW for 20ms)
AC Output: 220V / 230V / 240V AC, Selectable (±10% RMS)
Output Frequency: 50Hz / 60Hz (Auto-Sensing)
Input Voltage Range: 155–280V AC (For Personal Computers Mode)
Frequency Range: 40–80Hz (Auto-Sensing)
Inverter Efficiency (Peak): >88%
Line Mode Efficiency: >95%
Power Factor: 1
Transfer Time: 10ms (Max)
Charging System:- Three-Stage Charging: Maximizes battery life
- Adjustable Charge Current: Selectable at 25%, 50%, 75%, 100%
Usage: Residential & Commercial Backup Power, Off-Grid Solar Systems, Generator Integration, Critical Load Protection (Servers, Networking, Security), Utility & Telecom Power
