Device Type: 128-Channel 2U Intelligent Video Surveillance Server (IVSS)
Brand/Model: Dahua DHI-IVSS7108/H-V2
Video Output: 4× HDMI (up to 8K UHD / 7680×4320), 1× VGA; Supports multi-screen display
Data Ports: 4× RJ-45 Gigabit Ethernet (10/100/1000 Mbps); 4× USB; 1× eSATA; 1× RS-485; 1× RS-232; 16× Alarm In / 8× Alarm Out; 1× Audio In / 2× Audio Out
Processing & Capacity:- Processor: 64-bit High-performance multi-core processor
- Operating System: Embedded Linux
- IP Video Access: 128 Channels
- Network Bandwidth: Up to 768 Mbps incoming / 768 Mbps recording / 768 Mbps outgoing (drops to 512 Mbps if 8K output is enabled)
- Max Resolution: Up to 32 MP per channel
- Decoding Capability: 1-ch 32MP@30fps, 7-ch 12MP@20fps, 14-ch 8MP@15fps, 28-ch 1080p@30fps
Storage & RAID:- HDD Bays: 8× SATA (2U chassis)
- RAID Support: RAID 0/1/5/6/10/50/60
- External Storage: eSATA, iSCSI
AI Capabilities (AI by Camera):- Face Recognition: Up to 80-channel (2MP) or 60-channel (4MP) with face recognition IPC; 50 face databases with 500,000 pictures total
- Video Metadata: Human body, vehicle, and non-motor vehicle attributes
- IVS/Perimeter Protection: Tripwire, intrusion, abandoned/missing object, loitering, parking detection, etc.
- ANPR: 50 plate databases with 500,000 plate numbers; supports allowlist/blocklist
- Other AI: People counting, smoking detection, call detection, SMD
Physical & Environmental:- Form Factor: 2U Rackmount (19-inch)
- Dimensions: 439.7 × 446.2 × 89.0 mm
- Net Weight: 7.66 kg
- Power Input: 200–240 V AC
- Power Consumption: 38 W (typical) / 105 W (max)
- Operating Temperature: 0°C to +45°C
- Casing: Metal, Black
Key Specs: Dahua DHI-IVSS7108/H-V2, 128CH 2U Intelligent Video Surveillance Server, 64-bit Multi-Core Processor, Embedded Linux, 8× HDD Bays, RAID 0/1/5/6/10/50/60, Up to 32MP Resolution, 768Mbps Bandwidth, 4× HDMI (8K) + 1× VGA, AI by Camera (Face Recognition, ANPR, Metadata, IVS), 4× Gigabit LAN, 16 Alarm In/8 Out
Usage: Large-Scale IP Video Surveillance Management, Centralized Monitoring & Recording, AI-Powered Video Analytics (Face Recognition, ANPR, Metadata), Enterprise & Campus Security, Smart City & Critical Infrastructure Deployments
