Device Type: 10G Smart Managed Switch (Layer 2+ / Layer 3 Lite)
Model: D-Link DXS-1210-12SC
Ports:- 10x 10G SFP+ Ports
- 2x 10GBASE-T/SFP+ Combo Ports (Supports 100M/1G/2.5G/5G/10G)
- 1x RJ-45 Console Port
Performance:- Switching Capacity: 240 Gbps
- Forwarding Rate: 178.56 Mpps
- MAC Address Table: Up to 16,000 Entries
- Transmission Method: Store-and-Forward
Network Standards:- 10GBASE-T: Requires CAT6a or CAT7 Cabling (Up to 100m); CAT6 supports 30m max
- Fiber: Supports 10G SFP+ Transceivers and Direct Attach Copper (DAC) Cables
- Standards: IEEE 802.3u (Fast Ethernet), 802.3ab (Gigabit), 802.3an (10GBASE-T), 802.3ae (10GbE Fiber), 802.3az (Energy Efficient Ethernet)
Management & Features:- Layer 2: Port Mirroring, Spanning Tree Protocol (STP), Link Aggregation (LACP), IGMP/MLD Snooping
- Layer 3 Lite: Static Routing, IP Interfaces, ARP, IPv6 Neighbor Discovery
- QoS: Auto Surveillance VLAN (ASV), Auto Voice VLAN, DSCP Markings, Bandwidth Control
- Security: 802.1X Authentication, Access Control List (ACL), ARP Spoofing Prevention, DHCP Server Screening, D-Link Safeguard Engine
- Management: Web GUI, CLI (Telnet/Console), D-Link Network Assistant (DNA), D-View 7 Support, SNMP
Physical & Power:- Form Factor: 1U Rack-Mountable (Desktop Optional)
- Dimensions: 440 x 210 x 44 mm
- Weight: 2.72 kg (6 lbs)
- Power Consumption: 27.4W Max
- AC Input: 100-240V, 50/60Hz
- Cooling: Built-in Smart Fans (2 Fans)
Environmental:- Operating Temperature: -5°C to 50°C
- Storage Temperature: -40°C to 70°C
- Humidity: 0% to 95% Non-Condensing
Key Specs: D-Link DXS-1210-12SC, 10x 10G SFP+ + 2x 10GBASE-T/SFP+ Combo, 240 Gbps Switching, Layer 2+ Smart Managed, Layer 3 Lite Static Routing, Auto Surveillance VLAN, 802.1X, D-Link Green Technology, 1U Rackmount
Usage: SMB Network Core/Aggregation, Server-to-Server Connectivity, Virtualization & Cloud Services, Video Surveillance Backbone, VoIP Deployments
