- Device Type: Pure Sine Wave Inverter/Charger (Low-Frequency, Transformer-Based)
- Part Number/SKU: X1-1012 (also referenced as XH2i-1012)
- Brand: Shield
- Power Rating: 1000W (1KW) Continuous / 1000VA
- Surge Rating: 3000W (3KW) for 20ms
- Motor Starting Capacity: 1HP
- DC Input: 12VDC Nominal Battery Voltage
- AC Output (Battery Mode): 220V/230V/240VAC (±10% RMS)
- Output Frequency: 50Hz/60Hz ±0.3Hz (Auto-Sensing 40–80Hz)
- Output Waveform: Pure Sine Wave (Same as Input in Bypass Mode)
- Inverter Efficiency (Peak): >88%
- Line Mode Efficiency: >95%
- Power Factor: 1
- Typical Transfer Time: 10ms (Max)
- Charging System: 3-Stage Intelligent Charging with Adjustable Current (25%, 50%, 75%, 100%)
- Transformer: Built-in Pure Copper UI Transformer
- Display: LCD Panel + LED Indicators
- Communication: RS485 (Supports Remote Monitoring)
- Special Features: Automatic Generator Start Signal, DC Start, Auto Self-Diagnosis, Battery or AC Priority Function, Quiet Operation
- Protection Features: Overload Protection (Circuit Breaker), Output Short Circuit Protection (Circuit Breaker), Over-Temperature Protection, Low Voltage Alarm & Automatic Shutdown
- Mounting: Wall Mount
- Warranty: Standard Manufacturer Warranty (Confirm Region)
Key Specs: Shield X1-1012, 1KW Pure Sine Wave Inverter/Charger, 12VDC, 1000W Continuous / 3000W Surge (20ms), Low-Frequency Design with Pure Copper UI Transformer, LCD Display, 3-Stage Adjustable Charging, 220/230/240VAC Output, >88% Efficiency, 10ms Transfer Time, RS485 Communication, Generator Start Signal, Wall Mount, Quiet Operation
Usage: Home & Office Backup Power, Off-Grid Solar Systems, Areas with Unstable Utility Power, Powering Sensitive Electronics, Running Everyday Household Appliances (Lights, Fans, TVs, Computers, Routers)
