Massive 64-Zone Expandability
The IDS X64 is a hybrid security control panel that starts with
8 onboard zones and can expand to an impressive
64 zones using a combination of plug-in expanders, bus-wired expanders, and wireless receivers
. This makes it the most versatile and cost-effective 8-to-64 zone security system available, capable of protecting everything from a small home to a large commercial property
.
8 Independent Partitions with Stay Profiles
The system supports up to
8 separate partitions, each capable of being armed and disarmed independently. This allows different areas of a property to have separate security control without affecting other zones
. Each partition supports
4 stay profiles (Stay, Stay/Night, Home, Sleep), giving users flexible arming options for different scenarios
.
Hybrid Wired and Wireless Zone Support
The X64 is a true hybrid system, supporting both wired and wireless devices. It accepts up to
4 Xwave² wireless receivers, each supporting
16 bi-directional detectors for a total of
64 wireless zones . The wireless integration operates in the less congested
869MHz band with bi-directional communication for signal acknowledgment and encryption
.
Comprehensive User Management with 128 Codes
Up to
128 user codes can be programmed, with flexible authority levels including Master, Duress, Maid, Arm Only, Disarm Only, and Output Trigger
. The system also supports
8 tag readers for convenient access control
.
Advanced Arming Features
The X64 includes multiple quick-arm modes: Stay, Away, and Stay and Go . It also features Auto Arm/Disarm per partition by day of the week, No Movement Auto Arm (arms when no activity is detected), and Forced Arm (arms with violated zones temporarily bypassed) .
Expandable Outputs for Automation
The panel includes
5 programmable outputs onboard, expandable up to
41 outputs when using zone expanders, keypads, and output expanders
. These outputs can trigger sirens, strobes, lights, gates, and other peripherals for basic home automation
.
Integrated Keypad with Intuitive Controls
The included keypad provides easy arming, disarming, and system management with dedicated buttons for
Stay, Bypass, Chime, Panic, and Emergency functions
. The LCD keypad displays zone names, event logs, and programming menus for intuitive operation
.
1000-Event Date and Time Log
The system maintains an
event log of up to 1000 events with date and time stamps, allowing users and installers to review system activity, alarm triggers, and arming/disarming history
.
Multiple Communication Options
The panel includes a
multi-format digital communicator supporting Ademco, FBI, Silent Knight, Contact ID, and SIA protocols
. It features dual reporting to two independent central stations, split reporting, and fax defeat/answering machine override
. For remote management, the X64 supports
GPRS/3G modules with the
HYYP Smart App for iOS and Android
.
Support for up to 8 Keypads
The system can support up to
8 keypads connected via the keypad bus, allowing multiple control points throughout a property for convenient system operation
.
Robust Power and Battery Management
The X64 features
dual power supply with an independent battery charging circuit, providing
750mA auxiliary power for peripherals
. It includes
dynamic battery self-test,
low battery monitoring, and a
dedicated 500mA battery charger .
Bylaw 25 Compliant
The IDS X-Series alarm panels are
Bylaw 25 compliant, ensuring they meet South African regulatory requirements for security systems
.
